13. Product Diagram

13.1

Remote Control

MUTE: Silence the sound temporarily.
BGM: Play photo slideshow with background
music.
POWER: Power on/off switch.
PHOTO: Play photo slideshow.
MUSIC: Play music.
VIDEO: Play video.
: Pause or play the media again.
RETURN: Return to previous page.
: Move up/down/left/right cursor keys.
OK: Confirm or switch between pause/play
function in media play mode.
SETUP: Go to setup menu.
CALENDAR: See date and time.
VOL +/-: Turn up/down the volume.
ZOOM: Enlarge the photo in photo play mode
ROTATE: Rotate images 90° clockwise in the
photo play mode
: Move back to previous file in media play
mode.
: Move forward to next file in media play
mode.
13.2

Buttons

8. Power
9. UP
10. VOL +/Right
11. Play/Pause/O
K
12. VOL -/Left
13. DOWN
14. MENU
13.3

Ports

6. SD/MMC/MS Slot
7. Earphone Jack
8. USB port
9. MINI USB
10. DC IN
14. Installing & Replacing the Battery
Place the remote control upside down, press
down on the ridged area of the battery cover
and pull towards you to remove the tray.
Place one CR2025 lithium button-cell battery
on the tray with the positive "+" side facing
you. Reinsert the tray.
