INSTALLATION

Attachment

Before attaching the device, make sure that the installation area can hold a minimum point load of 10 times
the device's weight.
The device must only be installed absolutely planar at a vibration-free, oscillation-free and fire-resistant
location. Make sure that the device is installed absolutely planar by using a water-level.
The device must be installed out of the reach of people.
The device must always be installed via all fixation holes. Do only use appropriate screws and make sure
that the screws are properly connected with the ground.
The durability of the installation depends very much on the material used at the installation area (building
material) such as wood, concrete, gas concrete, brick etc. This is why the fixing material must be chosen to
suit the wall material. Always ask a specialist for the correct plug/screw combination indicating the maximum
load and the building material.
Procedure: (for articles 51914600, 51914605, 51914610)
Step 1: The holes for the installation are on the mounting bracket.
Step 2: Hold the mounting bracket onto the location where the device is to be installed.
Step 3: Mark the boreholes with a pen or a suitable tool.
Step 4: Drill the holes.
Step 5: Hold the mounting bracket in the desired position and fix it.
Step 6: Adjust the desired inclination-angle via the mounting-bracket and tighten the fixation screws.
Procedure: (for article 51914680, 51914684, 51914688)
Step 1: Loosen the fixation screw of the stake and remove the washer disk and the fixation screw.
Step 2: Place the stake onto the mounting bracket, place the washer disk on the other side of the
mounting bracket and tighten the fixation screw.
Step 3: Adjust the desired inclination-angle via the mounting-bracket and tighten the fixation screws.
Step 4: Install the device at the desired installation-spot.
Before taking into operation for the first time, the installation has to be approved by an expert!

Connection with the mains

Connect the device to the mains with the power plug. The occupation of the connection cables is as follows:
Cable Pin
Brown Live
Blue Neutral
Yellow/Green Earth
Attention! The earth has to be connected!
Permanent installation is recommended!

DANGER TO LIFE!

International
L
N
