Manual Instruction - Eskimo Optimum CC-2000 Bedienungsanleitung

CC2000_Eskimo_IM_204.qxp
1. Name of structure
Upper lid
Gasket
Water outlet
Casing
Base
Switch
Power cord
2. Brief of product
The unit is designed by separate style, means the base can
be separate from the whole unit, and the whole unit also
can be placed above the base at any directs, 360 rotary
base, more convenient. Stainless steel inner pot, very
healthful and not any chlorine, show fashion and style very
much. At the same time, the unit is heated by plane stain-
less steel base, not easy to form furring, and more easy to
clean.
Characteristics of product
A. When boiling is over, the unit will automatically switch to
keep warm.
B. Double dry-boiling protection apparatus + over tempera-
ture protection apparatus, very safety.
C. Bottom heater, boil speedly, save time.
D. Double structure, keep warm and save power, avoid
resulting to scald injury for the temperature of the shell
is higher than safe temperature.
E. Indicator light display, the working state is clear at a
glance.
2009-12-28 21:26 Page 9

MANUAL INSTRUCTION

Kettle + Thermos CC-2000 Eskimo
3. Operation instructions
When filling water, its level should not be higher then the fill
line; when using the unit for the first time, the boiling water
Switch for
can not be drinked. In order to insure the water is healthful,
water outlet
the inner pot should be cleaned careful after water is cool.
Lid lock
1. Fill with water.
Lid lockpin
Take out the unit from the base, open the lid and fill with
water, wipe off the water into the main body and the bottom.
Caution: When filling water, its level should not be higher
than the fill line, otherwise, hot water may overflow. At the
same time, the lid must be closed correctly.
2. Put the unit on the base.
Keep warm
indicator light
Boil indicator
light
Plug
3. When boiling is over, the unit will automatically switch to
4. When boiling is over, the boiling indicator light turns off,
5. Pour out water.
Take out the unit from the base, press the switch for obtain-
ing water, then you can obtain water from water outlet.
Caution:
During using the unit, take out the unit from the base every
time, the power supply will automatically turn off for insur-
ing safety. Then if you want to boil water or keep warm
again, the unit must be put on the base correctly and press
the switch of power supply again.
4. Points for attention
1. Please read the manual thoroughly before operating this
2. Do not connect this unit to power supply other than 230V
3. Use unilateralism fixed electrical outlet (10A, 230V), do
4. Do not put other things but water into the inner pot for
5. Do not immerse the unit in water for cleaning, the shell
(Black plate)
(1) When filling water is over, put the unit on the base,
and insure the unit has been put correctly on the
base.
(2) Press the switch of the power supply, boiling indicator
light grows on, boil water is beginning.
keep warm.
keep warm indicator light grows on, and automatically
stop heating.
unit.
AC outlet.
not cut, damage, twist, bundle the power cord, do not
place the unit too close to the pad that cannot endure
high temperature or on the wet place.
boiling, it may result to scald injury.
can be wiped off by the wet cloth, and the inner pot
should be cleaned by pickle or citric acid in regular.
UK
9
