large to dispose the tip it is necessary to put the ejector
cap "M" onto the ejector, (Fig. 6C).
- in 2 and 10 μl pipettes (Fig. 6D)
The 2 μl - 10 μl pipettes may require the use of an ejector
cap "M" to efficiently eject certain brands of pipette tips.
Simply place the cap, supplied with the pipette, on the
bottom of the pipette shaft and slide the cap upwards
until it surrounds the bottom of the tip ejector.
The LAB MATE Soft is a high quality instrument which
offers excellent accuracy and precision.
The accuracy and precision (repeatability) of liquid vol-
ume depend on the quality of tips used. The values for
accuracy and precision given in the table below were
obtained using HTL tips. Only those tips guarantee cor-
rect operation of the pipettes and ensure accuracy and
precision of liquid sampling.
Volume Accuracy
Model Cat. no.
[μl]
0.2
1.0
LM2
4811
Max 2.0
Min 0.5
5.0
LM10 4812
Max 10.0
Min 2
10
LM20 4813
Max 20
Min 5
25
LM50
4817
Max 50
Min 10
50
LM100 4814
Max 100
Min 20
100
LM200 4815
Max 200
Min 50
125
LM250
4810
Max 250
Min 100
500
LM1000 4816
Max 1000
Min 1000
2500
LM5000 4818
Max 5000
Min 1000
5000
LM10000
4819
Max 10000
3
Precision Tip Shafts
[%] [%] μl color
± 12.0 ± 6.0
± 2.7 ± 1.3
± 1.5 ± 0.7
10 μl red
± 4.0 ± 2.8
± 1.0 ± 0.6
± 0.5 ± 0.4
± 3.0 ± 1.5
± 1.0 ± 0.5
± 0.8 ± 0.3
± 2.5 ± 2.0
± 1.0 ± 0.6
± 0.8 ± 0.4
200 μl yellow
± 1.6 ± 0.80
± 0.8 ± 0.24
± 0.8 ± 0.20
± 1.2 ± 0.60
± 0.8 ± 0.25
± 0.6 ± 0.20
± 1.0 ± 0.4
300 μl green
± 0.8 ± 0.3
± 0.6 ± 0.3
± 1.6 ± 0.40
1000 μl blue
± 0.7 ± 0.20
± 0.6 ± 0.15
± 0.6 ± 0.25
5000 μl white
± 0.6 ± 0.20
± 0.5
± 0.15
± 2.5 ± 0.6
± 0.8 ± 0.3
10000 μl white
± 0.5 ± 0.2
The accuracy and precision are obtained with HTL tips,
using a gravimetric method, performing at least 10 mea-
surements of distilled water at a temperature of 20±1°C,
according to EN ISO 8655 standard.
The pipette design enables the user to perform the
recalibration process according to the rules presented in
section 8.

2 - SETTING THE VOLUME

The counter displays three figures to be read from top to
bottom. Additional to the figures on the lower wheel are
printed graduations to enable a volume setting in the
range increment of each pipette model.
Examples of the meaning of the black and red figures:
Pipettes LM2
Red figures at the bottom = 1/100 μl
Increment = 0.002 μl
Pipettes LM10, LM20,
Red figures at the bottom = 1/10 μl
Increment = 0.02 μl
Pipettes LM50, LM100,
LM200, LM250
Black figures only = 1 μl
Increment = 0.2 μl
Pipettes LM1000, LM5000,
Red figures at the top - ml
Increment =
Pipettes LM10000
Red figures at the top - ml
Increment = 20 μl
The volume of the pipette is set by the knob in the pipet-
ting pushbutton (Fig. 1A2) or by the black adjustment
knob (Fig. 1B). To attain the maximum accuracy, set vol-
ume must be approached from a higher value by dimin-
ishing counter readings.
ENGLISH
2 μl 10 μl
