TECHNICAL DATA

Parameter Parameter value
description
Product name Mosquito Insect Zapper Killer
Model CON.MK-6W CON.MK-16W
Rated power [W] 6 16
Rated voltage 230/50
[V~] / Frequency
[Hz]
Generated 1500-1800
voltage [V]
Action zone 360° 50-40 m
2
Bulb UV (F4T5BL) 2x 8 [W]
Protection class ll
Dimensions [mm] 120 x 120 x 275 350 x 115 x 280
Weight [kg] 0,5 2
Parameter Parameter value
description
Product name Mosquito Insect Zapper Killer
Model CON.MK-20W CON.MK-40W
Rated power [W] 20 40
Rated voltage 230/50
[V~] / Frequency
[Hz]
Generated 2000-2300
voltage [V]
Action zone 60-70 m 90-100 m
2 2
Bulb 2x 10 [W] 2x 20 [W]
Protection class ll
Dimensions [mm] 380 x 110 x 285 645 x 115 x 300
Weight [kg] 2,4 3

1. GENERAL DESCRIPTION

The user manual is designed to assist in the safe and
trouble-free use of the device. The product is designed
and manufactured in accordance with strict technical
guidelines, using state-of-the-art technologies
components. Additionally, it is produced in compliance
with the most stringent quality standards.
DO NOT USE THE DEVICE UNLESS YOU HAVE
THOROUGHLY READ AND UNDERSTOOD THIS
USER MANUAL.
To increase the product life of the device and to ensure
a trouble-free operation, use it in accordance with this user
manual and regularly perform the maintenance tasks. The
technical data and specifications in this user manual are up to
date. The manufacturer reserves the right to make changes
associated with quality improvement. Taking into account
technological progress and noise reduction opportunities,
the device was designed to reduce noise emission risks to
the minimum.
6
U S E R M A N U A L
Legend
The product satisfies the relevant safety
standards.
Read instructions before use.
The product must be recycled.
WARNING! or CAUTION! or REMEMBER!
Applicable to the given situation (general
warning sign).
Electric shock warning.
Do not touch.
Only use inside.
PLEASE NOTE! Drawings in this manual are for
illustration purposes only and in some details it
may differ from the actual machine.
The original operation manual is in German. Other
language versions are translations from German.
2. Usage safety
Electrical equipment:
ATTENTION! Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in an electric shock, fire and/
or serious injury or even death.
Whenever „device" or „product" are used in the warnings
and instructions, it shall mean Mosquito Insect Zapper
Killer. Do not use in very humid environments or in the
direct vicinity of water tanks. Prevent the device from
getting wet. Risk of electric shock! When in use, do not put
your hands or other items inside the device!
3.1 Electrical safety
a) The plug has to fit the socket. Do not modify the
plug in any way. Using original plugs and matching
sockets reduces the risk of electric shock.
b) Avoid touching earthed elements such as pipes,
heaters, boilers and fridges. There is an increased
risk of electric shock if the earthed device is exposed
to rain, in direct contact with a wet surface or
operating in a humid environment. Water ingression
into the device increases the risk of damage to the
device and of electric shock.
c) Use the cable only in accordance with its designated
use. Never use it to carry the device or to pull the
plug out of a socket. Keep the cable away from heat
sources, oil, sharp edges or moving parts. Damaged
and
or tangled cables increase the risk of electric shock.
d) If using the device in a humid environment cannot
be avoided, a residual current device (RCD) should
be applied. The use of an RCD reduces the risk of
electric shock.
3.2 Safety at the workplace
a) Make sure the workplace is orderly and well
lit. A messy or poorly lit workplace may lead to
accidents. Try to anticipate what may happen,
observe what is going on and use common sense
when working with the device.
b) Do not use the device in an explosion hazard zone,
for example in the presence of flammable liquids,
gasses or dust. The device generates sparks which
may ignite dust or fumes.
c) Upon discovering damage or irregular operation,
immediately switch the device off and report it to
a supervisor without delay.
d) If there are any doubts as to the correct operation
of the device, contact the manufacturer's support
service.
e) Only the manufacturer's service point may repair the
device. Do not attempt any repairs independently!
f) If a fire starts, use solely powder or carbon dioxide
) fire extinguishers suitable for use on live
(CO
2
devices to put it out.
g) Children or unauthorised persons are forbidden
from entering a work station. (A distraction may
result in a loss of control over the device).
h) The device should be used only in closed rooms and
protected from weather conditions.
i) Make sure that there is a sufficient space around the
device for proper air circulation.
j) The device is not suitable for use in barns, stables,
etc.
REMEMBER! When using the device, protect children
and other bystanders.
3.3 Personal safety
a) Do not use the device when tired, ill or under the
influence of alcohol, narcotics or medication which
can significantly impair the ability to operate the
device.
b) When working with the device, use common sense
and stay alert. Temporary loss of concentration
whilst using the device may lead to serious injuries.
c) To prevent the device from accidentally switching on,
make sure the switch is on the OFF position before
connecting to a power source.
d) Do not overestimate your abilities. When using the
device keep your balance and remain stable at all
times. This will ensure better control over the device
in unexpected situations.
e) Do not touch the device with wet hands or other
parts of the body.
3.4 Safe device use
a) Do not overload the device. Use appropriate tools
for the given task. A correctly selected device will
perform the task for which it was designed better
and in a safer manner.
b) Do not use the device if the ON/OFF switch does not
function properly (does not switch the device on and
off). Devices which cannot be switched on and off
using the ON/OFF switch are hazardous, should not
be operated and have to be repaired.
c) Make sure the plug is disconnected from the
socket before attempting any adjustments, tool
replacements or before putting the device aside.
Such precautions will reduce the risk of accidentally
activating the device.
d) When not in use, store in a safe place, away from
children and people not familiar with the device, who
have not read the user manual. The device may pose
a hazard in the hands of inexperienced users.
e) Maintain the device in a good technical state. Before
each use check for general damage and especially
check for cracked parts or elements and for any other
conditions which may impact the safe operation of
the device. If damage is discovered, hand over the
device for repair before use.
EN
f) Keep the device out of the reach of children.
g) Device repair or maintenance should be carried out
by qualified persons, only using original spare parts.
This will ensure safe use.
h) To ensure the operational integrity of the device, do
not remove factory fitted guards and do not loosen
any screws.
i) Do not cover the device in the course of operation as
this may cause danger of overheating.
j) Do not insert any objects into the openings of the
device.
k) It is not allowed to use this device with a controller,
clock or other appliance that automatically turns on
the device, as there is a risk of fire if the device is
covered or set incorrectly.
l) It is not allowed to touch the grid with metal objects,
even if the main switch is set to the OFF position,
there is a risk of a slight but unpleasant electric shock
and the generator may be damaged.
m) This device is not intended to be used by persons
(including children) with limited physical, sensory or
mental aptitude, as well as lack of experience and/or
knowledge, unless they are supervised by a person
responsible for their safety or if they have received
instructions as to how the device is used.
4. Use guidelines
The insecticide lamp is designed for exterminating flying
insects that are lured by light. Lured insects are killed by
electric shock. The device can be suspended on the ceiling,
shelf or free-standing. The device must not be used outside
of buildings.
The user is liable for any damage resulting from non-
intended use of the device!
4.1 Device description
CON.MK-6W CON.MK-16W, CON.MK-20W,
CON.MK-40W
1
3
2
2
1. Holder for 1. Main switch of the device
hanging 2. Tank
2. Unscrewed 3. Holders for hanging
bottom/tank
4.2 Preparing for use
The device should be used only in closed rooms and
protected from weather conditions.
The temperature of environment must not be higher than
40°C and the relative humidity should be less than 85%.
Ensure good ventilation in the room in which the device
is used. The distance between each side of the device and
the wall or other objects should be at least 10 cm. Keep the
device away from hot surfaces.
