Ultrasonic-Sensors
Operating Instructions
zws-15/CD/HV/QS
zws-15/CE/HV/QS
Ultrasonic proximity sensor with
one switched output
Safety advice
Read the operating instructions
I
before starting operation.
Connection, assembly and set-
I
tings only by competent techni-
cians.
Not a safety device in accordance
I
with EU machine guidelines.
Proper use
zws ultrasonic sensors are used for
non-contact detection of objects.
Mounting
Install sensor on the fitting place.
I
Connect cable to M8 connector.
I
Starting operation
Switch on power supply.
I
Adjustment according to dia-
I
gram.
1
1)
Set switching point
Set window mode
➀
Position object at
Position object at
Press button for about
Press button for about
3 seconds, until both
3 seconds, until both
LEDs flash
simultaneously
both LEDs:
flash in turn
both LEDs:
Position object at
Press button for
about 1 second
The content of this document is subject to technical changes. Specifications in this document are presented in a
descriptive way only. They do not warrant any product features.
Operation
The sensor has three operation
modes
Operation using one switching
I
point
Window mode
I
Reflective barrier
I
Synchronisation
You can synchronize as many sen-
sors as you like.
Apply a square-wave signal to
I
the sync-input
pulse width t
> 150 µs,
i
repetition rate t
= 8 ms...1 s.
p
A high level on the synchro-input
will deactivate the sensor.
sensor disabled
+U
B
start
-U
B
t
> 150 µs
8 ms < t
< 1 s
i
p
External synchronisation signal
Maintenance
microsonic sensors are mainte-
nance-free. In case of excess caked-
on dirt we recommend cleaning the
white sensor surface.
Checking operation mode
In normal mode shortly press the
I
pushbutton.
The green LED stops shining for one
second, then it will show the current
operating mode:
1 x flashing = operation with one
switching point
2 x flashing = window mode
3 x flashing = reflective barrier
1
2
1)
Set reflective barrier
➀
Position reflector at
Press button for about
3 seconds, until both
LEDs flash
LEDs flash
simultaneously
simultaneously
flash in turn
both LEDs:
➁
Press button for
Press button for
about 1 second
about 10 seconds
(green LED on, yellow LED shows the state of the switching output)
Angle of beam spread
Transducer frequency
Resolution, sampling rate
Operating voltage U
No-load current consumption
Class of protection acc. to
Type of connection
sensor disabled
Operating temperature
Storage temperature
Switching hysteresis
Switching frequency
Time delay before availability
1) Keep in mind the temperature drift of the switching point, e.g. for each change in temperature
amounting to 10° C, teach a 1.7 % higher switching point.
After a break of 3 s the green LED
shows the output function:
1 x flashing = make function
2 x flashing = brake function
CE
89/336/EEC
1
Set n.c / n.o.
➀
Press button for about
13 seconds, until both
LEDs flash
simultaneously
flash in turn
green LED:
flashes
yellow LED:
on: n.o.
off: n.c.
Press button for about
1 second in order to
change setting
wait for 10 s
Standard operation
microsonic GmbH • Hauert 16 • D-44227 Dortmund • Tel: +49 2 31 / 97 51 51-0 • Fax: +49 2 31 / 97 51 51-51
60 m m
40 m m
20 m m
0 m m
20 m m
40 m m
60 m m
Blind zone
20 mm
Operating range
150 mm
Maximum range
250 mm
See detection zone
380 kHz
0,20 mm
Reproducibility
± 0,15 %
Accuracy
Temperature drift 0,17 %/°C
20 - 30 V DC, reverse polarity protection
B
Voltage ripple
±10 %
< 25 mA
Housing
ABS, ultrasonic sensor: polyurethane foam, epoxide resin
with portions of glass
IP 67
EN 60 529
4-pin M8 initiator plug
Controls
Teach-in pushbutton
Indicators
LED green (working)
LED yellow (state of output)
Programmable
No
Synchronization
Yes, external
-20°C to +70°C
-40°C to +85°C
Weight
10 g
Switched output
pnp, U
-2 V
B
I
= 200 mA
max
switchable NOC/NCC, short-circuit-proof
2 mm
25 Hz
Response time
40 ms
< 300 ms
Norm conformity
EN 60947-5-2
Order no.
zws-15/CD/HV/QS
1
2
2
4
U
4
1
3
3
Enable/disable
Teach-in pushbotton
Switch off power supply
Switch on power supply
while pressing down
and holding the push-
button
Keep button pressed
down for about
3 seconds, until both
LEDs flash
simultaneously
green LED:
flashes
yellow LED:
on:pushbut-
ton enabled
off: pushbut-
ton disabled
Press button for about
1 second in order to
change setting
wait for 10 s
aligned plate
pipe (10 mm Ø)
150 mm
detection range
*B4716*
1)
npn, -U
+2 V
B
zws-15/CE/HV/QS
1
+U
+U
B
B
2
Sync
Sync
U
4
3
-U
-U
B
B
Back to factory setting
Switch off power supply
Switch on power supply
while pressing down
and holding the push-
button
Keep button pressed
down for about 13
seconds, until green LED
is illuminated
E-Mail: info@microsonic.de • www.microsonic.de
