4. To secure the AXIS 225FD camera unit to the pendent adapter, push
the supplied bolts through the camera unit and place a washer on each
bolt (see illustration below) . Make sure the gasket is properly aligned
and secure the bolts in the screw holes in the pendent adapter.
AXIS 225FD
camera unit
5. Refer to the AXIS 225FD Installation Guide for instructions on how to
complete the installation.
The installation guide is available from the Axis web site at:
www.axis.com
AXIS 225FD Pendent Kit - Installation Guide
Cable gland
Washers (3)
Product label with
serial number (S/N)
Bolts (3)
