SMS C591U005-2C0 Handbuch Für Installation Und Anpassung Seite 22

22 SMS PRESENCE W/F 150 MOTOR
PRODUCT DIMENSIONS
SMS Presence W/F Motor 150 1200x600
10,335
262 + 37,5 ( 1,476 ) - 15 ( 0,590 )
5,677
144 + 37,5 ( 1,476 ) - 15 ( 0,590 )
B
3,650
93
5,906
150
DETAIL B
SCALE 1 : 2
All dimensions in mm
Dimensions in brackets are in inches.
Vesa: min 200 - max 1200
29,751
756
21,969
558
53,150
1350
0,591
15
in after instalations
