IntesisHome® LG-RC-WIFI-1
Installation pocess should only be performed by an authorized installer.

1. Product description

The IntesisHome device is an external module capable of connecting LG Air Conditioning units into your Wi-Fi
network in order to provide global connectivity and remote control applications through a friendly user interface.
Packaging content:
• IntesisHome Device
• Quick start guide

2. Technical information

In order to obtain a complete and technical description of the device, please see the document at
www.intesishome.com/docs/LG-RC-WIFI-1-Technical-Info-eng.pdf
1. Lid
2. LED indicator
3. Antenna Connector
4. Push button
5. AC connector
6. DIP-Switch
In order to obtain detailed description of the installation possibilities, please see the document at
www.intesishome.com/docs/LG-RC-WIFI-1_Install_Sketch.pdf
3. FAQ and support
For any question or problem related with the product or the installation procedure, please visit our support
center at www.intesishome.com/support/faq.
Please refer to the website
Please follow all Safety Instructions provided by the LG manuals.
• External Antenna

• Installation guide

www.intesishome.com/downloads
INSTALLATION GUIDE
• Warranty Doc
for latest updates.
Figure 1
