E N
FILTRATION.
The water in the pool enters the multifunctional valve from the PUMP connector (Fig. 13,
# 1), travels through the filter media (from top to bottom), exits from the POOL connector
(Fig. 13, # 3) and returns clean to the pool.
BACKWASH.
The water in the pool enters the multifunctional valve from the PUMP connector (Fig. 13,
# 1), travels through the filter media (from bottom to top) stirring it, exits from the WASTE
connector (Fig. 13, # 4) getting rid of the impurities held back by the filter media.
RINSE.
The water in the pool enters the multifunctional valve from the PUMP connector (Fig. 13,
# 1), travels through the filter media (from top to bottom) compacting it, exits from the
WASTE connector Fig. 13, # 4) ) getting rid of the impurities held back by the filter
media.
VALVE CLOSE (only on 6-way multifuncional valve).
The water in the pool does not cross the filter. The PUMP connector (Fig. 13, # 1) is
closed.
WASTE (only on 6-way multifuncional valve).
The water in the pool enters the multifunctional valve from the PUMP connector (Fig. 13,
# 1), exits straight from the WASTE connector (Fig. 13, # 4) without going through the
filter media.
CIRCULATION (only on 6-way multifuncional valve).
The water in the pool enters the multifunctional valve from the PUMP connector (Fig. 13,
# 1) and exits from the POOL connector (Fig. 13, # 3) going back to the pool without
crossing the filter media.
WINTER.
Rest position of the multifunctional valve to protect the internal components of the
multifunctional valve itself. Position suitable for storage.

8. Routine, scheduled and extraordinary maintenance.

Before proceeding with any maintenance activity, remember to disconnect the power plug from the power outlet, and not to put your hands in the water if the
product (pump) is turned on.
Do not lubricate and/or use detergents and/or chemical products to clean the product.
Replace damaged components and/or deteriorated as quickly as possible, use only original spare parts. For this purpose, please consult the "Retail and spare
parts and relevant documentation".
8.1. Routine maintenance.
To be performed at least once a year, or more frequently if necessary.
The filter maintenance is limited to its own cleaning through the BACKWASH. Start it at least once a week for 2-3 min. and after each bottom cleaning.
Carry out a BACKWASH after each cleaning of the bottom or when the pressure on the gauge equals the pressure stated in Tab. 1 (backwash).
A rinse of about 30 seconds must follow each BACKWASH.
It is essential to filter twice a day for 4-5 hours, to regularly backwash (for 2÷3 minutes) and to wash the pool bottom at least once a week so that the pool water
remain cleaned!
Nome file:
20.10.326 - ISTRUZIONI SF 15-200 _BIDONE SF
File name:
Tab. 7
