MT5600ZDX/ZDXV Quick Start Guide
28
V.34. This LED is lit when the modem is connected in V.34 mode.
14
V.32 bis . This LED is lit when the modem is connected in V.32 bis mode. Note that
at speeds lower than a V.32 bis connection, the MultiModemZDX speed LEDs
remain unlit.
OH
Off Hook. The condition of Off Hook indicates to the central office that the
MultiModemZDX wants the phone line to do something (i.e., dial or answer a call).
This LED is also lit when the MultiModemZDX has achieved on-line status.
TR
Terminal Ready. When TR is lit, the MultiModemZDX can answer an incoming call.
This signal (TR or DTR) provides a means for the terminal or computer to control
the MultiModemZDX's connection to the communications channel.
A high DTR signal is required by the MultiModemZDX to be able to communicate.
The state of the TR LED matches that of the DTR circuit on pin 20 of the RS232/
V.24 interface.
EC
Error Correction. This LED is lit when the modem is set for V.42 error
correction, and flashes on and off when data compression is activated.
FX
Fax. This LED is lit when the modem is connected in Fax mode.
