Information
Operating instructions
When using the PipeBench 170 certain safety equipments are required. In addition to
these instructions, always follow the offi cial work, health and safety regulations. The
Exact PipeBench 170 is meant for professional use only.

Technical data

Model
Weight
For pipes Ø
Length
Bench height
Working height
Maximum load

Intended use

The Exact PipeBench 170 is intended for professional use at all different type of construction sites. The
accessories are designed to be used with 15-170 mm pipes. The saw holder is designed for Exact PipeCut
models 170 170E and 220E. The Exact PipeBench 170 should be used only on an even fl oor.
WARNING: When placing heavy pipes on the Exact PipeBench 170, pay extra attention that they
do not fall off the pipe bench and cause injury to the operator or damage to the fl oor surface.
How to use Exact Pipe Bench 170
Push to release
the legs. Shake
if they do not
open.
Turn t
he legs
untill they
get locked
PipeBench 170
12,1 kg (26.1 lbs)
15 mm -170 mm (0.6"-6.7")
1180 mm -2510 mm (46.5"-98.8")
700 mm (27.5")
875 mm -1030mm (34.4"-40.5")
100 kg (220 lbs)
Handle to
carry the
bench
Open to adjust
the length
Pull to adjust
the length
Pipe Supports
and Chain Vice
can be also
attached here
2
Saw holder
for Exact
170/170E
and 220E
Tool Bag can
be hanged to
the hooks
english
