Teileliste - Maxxus MX 7.1 Montageanleitung

Teile-Nr. Bezeichnung
1 Frame components
2 Neck movement
3 Double robot
4 Plastic Rail Patch
5 Pan head tapping screw
6 Right armrest assembly
7 Speaker inner cover left components
8 Speaker cover left
9 Cross recessed pan head screws
10 Speaker cover
11 Power switch components
12 Buttock Airbag
13 Cup holder
14 Cup holder support frame trim
15 Cup holder
16 Pan head tapping screw
17 QR code sticker
18 Cup holder sticker
19 Hand control panel components
20 Hand control panel sticker
21 Air pump silencer box components
22 Cross recessed pan head tapping screws
23 Front rail components
24 Cross recessed pan head screws
25 Chassis
26 buttock Airbag
27 Left armres components
Drive box components
28
Speaker inner cover left assembly
29
Speaker cover left
30
Rear cover
31
Upper rail
32
Leather case components
33
Cushion components
34
Head components
35
36
power cable

Teileliste

13
