6. Piping
The pipe system should be made of stainless steel pipes. The pipe joints
should be made in a way that makes separation possible in case of e.g.
repairs, movement or similar.
Pipe connections BW3
Water 5/4" RG
Pipe connections BF3
Water 5/4" RG
Pipe connections
Water 2 1/2" RG
* In order to secure an always suffi cient water fl ow and a minimum pressure
loss the dimension of the pipe connection to the BW8 unit has been made a
bit bigger than the dimension of the rest of the BW8 piping.
Note: A 5/4" - 2" closing valve should be mounted on the water supply im-
mediately before the Booster and dirt fi lter if any.
7. Assembly
Dimensions see fi g.1 - fi g.3
It is recommended to mount the Booster at an appropriate height (approx.
1 m above the fl oor) on a brick or concrete wall, according to the mount-
ing instructions. To make the mounting easier, it is recommended to mark
auxiliary lines on the wall according to fi g. 4. The Booster must be lifted in
this way that the auxiliary point on the right of the cabinet is fl ush with the
horizontal and the vertical auxiliary lines on the wall, after which the Booster
is hung over the fi tting.
Tighten the Booster with the enclosed screws and rawlplugs.
BW4 BW8
5/4" RG 2" RG*
BF4 BF8
5/4" RG 2" RG*
BF16 BF24
3" RG
