SOPRO COMEG SYMBIOZ Flow Betriebsanleitung Seite 11

2
inTRODUCTiOn TO The APPARATUs
The table below describes the back and front components
C1 external desufflation valve
C2 CO2 outlet
C3 Mains socket
C4 service
C5 Connection to sopro camera
C6 CO2 input
C7 equipotential socket
l1 Touch screen
s1 standby switch
s2 Power switch
i label
