Princeton Tec EOS Bedienungsanleitung

Princeton Tec cares about the environment and
recommends recycling batteries. For more
information about battery recycling, please go to:
www.batteryrecycling.com
Observe proper battery polarity when installing the
batteries. Improper installation of the batteries will
damage the light and void the warranty.
• Never mix fresh and used batteries.
• Never mix different battery brands or chemistry
types.
• Always remove drained batteries immediately.
• Remove batteries during long periods of storage.
NOTE: Lithium batteries offer extended constant
brightness time, extreme cold weather
performance, and are lighter weight. Rechargeable
NiCad or NiMH batteries may result in reduced
brightness due to lower nominal voltage.
The EOS battery compartment has a waterproof
seal. It is important to keep this seal free from dirt
and away from harsh chemicals in order to
preserve waterproof integrity. Inspect the seal
every time batteries are changed. If dirt is present,
wipe gently with a damp cotton swab and mild
soap until dirt is removed.
NOTE: Some battery types can emit hydrogen gas,
which can create an explosion potential in sealed
devices if it is not vented or removed. The EOS is
equipped with a platinum catalyst to remove this
gas. Upon severe impact, the catalyst could
fracture. If you notice a rattling sound in the
headlamp or gray particles in the battery
compartment, do not use the headlamp. See the
warranty and return policy for more information.
Modes (High, medium, low and flash) are selected
by pressing and releasing the button within 1.5
seconds of the previous button press.
There are two ways to turn the EOS off. You can
cycle through the modes until you reach off or if more
than two seconds have passed since the previous
button press, holding the button for 1.5 seconds will
turn the light off.
Circuitry and Power Consumption / Regulated Leds
See Regulated LED diagram
The EOS uses a sophisticated current-regulating
circuit that maintains initial brightness as long as the
batteries have sufficient voltage.
Troubleshooting
If the EOS fails to light:
• Check the batteries for proper installation.
• Replace batteries if proper installation is confirmed
• Check circuit board for water (the seal may have
been compromised by improper rear cover
installation). The light will resume normal operation
once the water is shaken or blown out and the light
is left open until completely dry. If the light has
been contaminated with salt water, flush the unit
with fresh water and dry as described above.
USA Lifetime Warranty -
International 10-Year Warranty
Due to International regulations, Princeton Tec's
lifetime warranty can only be offered to customers
in the USA. Princeton Tec offers a 10-year warranty
to our customers outside the USA. FULL
WARRANTY - Princeton Tec warrants this product
to be free from defects in workmanship and
materials under normal use for as long as you own
this product. This warranty covers all of the
component parts of the product except batteries.
This warranty does not cover deterioration due to
normal wear or damage due to misuse, alteration,
negligence, accidents, or unauthorized repair.
Princeton Tec will repair or replace parts which are
defective In workmanship or materials. Your
authorized Princeton Tec Dealer and Princeton Tec
are the only facilities authorized to repair the
product. After (3) unsuccessful attempts to repair
the product, you have the right to elect replace-
ment of the product
or a refund of the purchase price less allowance for
use of the product. NO INCIDENTAL OR
CONSEQUENTIAL DAMAGES ARE INCLUDED IN
THIS WARRANTY. (Some states do not allow the
exclusion or limitation of incidental or consequen-
tial damages, so the above limitations or
exclusions may not apply to you.)
informationabout informationabout informationabout 97H 92H
Total Total
26 61
This warranty gives you specific legal rights, and
you may also have other rights which vary from state
to state.
Princeton Tec reserves the right to change product
specifications without notice.
FOR CALIFORNIA RESIDENTS:
WARNING: This product contains Bisphenol A
(BpA) a chemical known to the State of California
to cause birth defects or other reproductive harm.
Return Policy
If your light fails to operate, follow these
simple steps:
1) Check batteries. Replace if necessary.
2) To send your light in for repair or replacement,
first contact Princeton Tec customer service on
1-800-257-9080 to request an RMA number.
Please have your light model, date of purchase
and a brief description of the fault you are
experiencing. No warranty repairs will be accepted
without an RMA number.
3) Return the light without batteries to:
Princeton Tec, PO Box 8057 Trenton NJ 08650
Postage due and freight collect items will not
be accepted.
4) Upon receipt your light will be processed in
about two weeks. Please allow additional time for
return transportation from New Jersey
This equipment is suitable for use in Class 1, Division
2, Groups A, B, C and D Hazardous Locations or
non-hazardous locations only.
WARNING - Risk Of Ignition - Do not open in
hazardous area.
WARNING - Risk Of Ignition - Do not change batteries
in hazardous area.
WARNING - Explosion Hazard - Substitution of
components may impair suitability of Class 1, Division 2.
Princeton Tec
PO Box 8057, Trenton,
NJ 08650
Phone: 609-298-9331
Fax: 609-298-9601
www.princetontec.com
© 2017 Princeton Tec
86H
Total
92H
Total
86
