Rodcraft RC7009 Bedienungsanleitung Seite 2

Air Supply Diagram
1/4 BSP
Speed Power
Model
[RPM] [W]
1 2
RC7009 30,000 300
RC7058 23,500 700
3/8" (10mm)
Air consumption
Collet
Average Continuous
[mm]
[NL/min]
3
4
6
144 564
6
288 1146
1/2" (12mm)
Fig. 01
L
Start
Fig. 02
Start
Fig. 03
Dimension
Weight Air Inlet.
LxWxH
W
L
[kg] [mm] [in.]
5 6 7
0,37 150*34*34 1/4"
0,82 199*45*45 1/4"
1/2" (12mm)
(1/2") NPT
90
0 130
(1/2") NPT
(1/2") NPT
H
A
A
Inner hose Sound Sound
diameter Pressure Power
[mm] [dB(A)] [dB(A)]
8 9
10 85.7 96.7
10 92.7 103.7
Vibrations
ahd k
[m/s ] [m/s ]
2 2
10 11 12
3.33 0.75
1.82 0.61
