4
Connect the cables and power cord
1. Connect the mouse and keyboard cables into the cor-
responding connectors at the back of the server.
2. Place your monitor near your server. Connect the
monitor signal cable to the back of the monitor and
then connect it to the matching connector at the back
of your server. Note that some monitors have signal
cables permanently attached.
3. Connect the monitor power cord to the back of the
monitor if necessary, and then connect it to the match-
ing connector at the back of your server or into a wall
outlet.
NOTE
Some large screen monitors (17-inch diagonal and over)
require more power than the server's auxiliary ac outlet
can supply. These monitors will have power cords that
must be connected directly into a wall outlet.
6
4. Connect the server power cord to the server, then to
your power outlet.
NOTE
If you have a secondary power supply, connect the
remaining ac power cord to the secondary power supply,
then to your power outlet.
CAUTION
Do not attempt to modify or use an external
100 Vac (Japan only) or 115 Vac power cord for
240 Vac input power. Modifying either cord can
cause severe equipment damage.
DIGITAL Server 5100/5200 Series
