Conceptronic CCHATCAM Schnellinstallationsanleitung Seite 6

ENGLISH
2. Specifications
Function/Feature
Camera Sensor
Pixel
Resolution
Frame Rate
Power Consumption
Focus Distance
White Balance
Exposed Control
Image Format
Operating System
Built in microphone
Snapshot Button
Lens Adjustable
3. Computer Requirements
•
CD-ROM Drive
•
One (free) USB port
•
Operating Systems: Windows 98SE/ 2000/ Me and XP
•
RAM Memory: 64MB or above
4. Driver Installation
! Please do not insert the Chatcam PC Camera into the USB port before
completing the driver installation
Please make sure that you have Windows 98SE/ 2000/ Me or XP running and
working, before attempting to install Chatcam camera driver.
1. Insert the Chatcam PC Camera Driver CD-ROM into CD-ROM drive and
the installation program will start automatically.
2. If the installation program does not start automatically, click on 'Start->
Run'. Type 'x:/setup.exe', (assuming X is your CD-ROM drive).
3. Click 'Driver' in the menu. The installation of the driver will start. Click
'next'.
CMOS
640 x 480 (VGA format)
640 x 480, 352 x 288, 320 x 240, 160 x 120
Up to 15fps for 640 x 480
Up to 30fps for 352 x 288
USB interface supplies power
+5V DC, 150mA
30cm ~ infinity
Automatic
Automatic
RGB
Windows 98(SE)/2000/Me/XP
Yes
Yes
Yes
- 2 -
Specification
