elc multiplay centre Montageanleitung Seite 9

assembly
step 4
M4 x 40 x8
D2310 x1
D2309 x1
D2018 x1
16 x 68 x 460mm 16 x 68 x 444mm
44 x 68 x 1170mm
step 5
D2019 x1
D2020 x1 M8 T-Nut x3
28 x 68 x 200mm
28 x 68 x 635mm
Page 09
