English
4. Disconnect the charger's power cord from the
receptacle.
5. Hold the charger fi rmly and pull out the battery.
NOTE
Be sure to pull out the battery from the charger after use,
and then keep it.
Regarding electric discharge in case of new
batteries, etc.
As the internal chemical substance of new batteries and
batteries that have not been used for an extended period
is not activated, the electric discharge might be low when
using them the fi rst and second time. This is a temporary
phenomenon, and normal time required for recharging
will be restored by recharging the batteries 2 – 3 times.
How to make the batteries perform longer.
(1) Recharge the batteries before they become completely
exhausted.
When you feel that the power of the tool becomes
weaker, stop using the tool and recharge its battery. If
you continue to use the tool and exhaust the electric
current, the battery may be damaged and its life will
become shorter.
(2) Avoid recharging at high temperatures.
A rechargeable battery will be hot immediately after
use. If such a battery is recharged immediately after
use, its internal chemical substance will deteriorate, and
the battery life will be shortened. Leave the battery and
recharge it after it has cooled for a while.
CAUTION
○ If the battery is charged while it is heated because
it has been left for a long time in a location subject to
direct sunlight or because the battery has just been
used, the charge indicator lamp of the charger lights
for 0.3 seconds, does not light for 0.3 seconds (off for
0.3 seconds). In such a case, fi rst let the battery cool,
then start charging.
○ When the charge indicator lamp fl ickers (at 0.2-second
intervals), check for and take out any foreign objects in
the charger's battery connector. If there are no foreign
objects, it is probable that the battery or charger is
malfunctioning. Take it to your authorized Service
Center.
○ Since the built-in micro computer takes about
3 seconds to confi rm that the battery being charged with
UC18YSL3 is taken out, wait for a minimum of 3 seconds
before reinserting it to continue charging. If the battery
is reinserted within 3 seconds, the battery may not be
properly charged.

PRIOR TO OPERATION

○ Setting up and checking the work environment
Check if the work environment is suitable by following
the precautions.

USING THE CONTROLS

(FUNCTIONS)
● The mode switch functions (Fig. 4)
NOTE
The turbo mode turns off automatically and
returns to the previous mode after 10 seconds
in order to protect the electronic circuitry. Press
the turbo mode switch again to switch back to
the turbo mode.
● Work Capacity on a Full Charge
The following is a rough estimate of the amount of
work provided by the blower when on a full charge.
(The amount of work varies somewhat due to ambient
temperature and characteristics of the battery)
Time in continuous operation when switch fully depressed
in each mode
Battery
Mode
Mode 1
Mode 2
Mode 3
Mode 4

MOUNTING AND OPERATION

Action
Inserting the battery cover
Charging
The mode switch functions
Mounting the extension nozzle
Removing and inserting the
battery
Turning the blower on
About remaining battery indicator
Charging a USB device from a
electrical outlet
Charging a USB device and
battery from a electrical outlet
How to recharge USB device
When charging of USB device is
completed
Selecting accessories
ABOUT USB DEVICE
○ Charging a USB device from an electrical outlet.
(Fig. 9-a)
○ Charging a USB device and battery from an electrical
outlet. (Fig. 9-b)
○ How to recharge USB device. (Fig. 10)
○ When charging of USB device is completed. (Fig. 11)

MAINTENANCE AND INSPECTION

1. Inspecting the nose grill
Before and after use, check and make sure the nose
grill, which covers the air intake, is not damaged. If it
is damaged, contact your sales outlet or the Hitachi
Authorized Service Center to have it repaired.
2. Inspecting the mounting screws
Regularly inspect all mounting screws and ensure that
they are properly tightened. Should any of the screws be
loose, retighten them immediately. Failure to do so could
result in serious hazard.
3. Maintenance of the motor
The motor unit winding is the very "heart" of the power
tool.
12
BSL36A18
29.5 min.
19.5 min.
13 min.
9.5 min.
Figure Page
2 2
3 2
4 2
5 3
6 3
7 3
8 3
9-a 4
9-b 4
10 4
11 4
