PART DESCRIPTIONS

1
3
4
5
6
8
10
1. HANDLE
2. RETRACTABLE HANDLE
3. RUGGEDIZED HOUSING
4. METAL MESH GRILL
5. POWER ON/OFF KEY
6. LINE IN
7. DC (15V, 2A
8. USB PORT
9. 1A CHARGER (5V)
10. MIC PORT1
11. MIC PORT2
12. WHEELS
13. POWER INDICATOR
14. BLUETOOTH INDICATOR
2
3
7
9
11
12
) INPUT
13 14 15 16 17
26 25 23
24
15. LED DISPLAY
16. BATTERY LOW INDICATOR
17. BATTERY FULL INDICATOR
18. LED LIGHT
19. ECHO (DOWN/UP)
20. MIC VOLUME (UP/DOWN) KEY
21. PAUSE/PLAY
(DISCONNECT) KEY
22. VOLUME (+/-) ROTATE
23. SOURCE/BT PAIR
24. TUNING DOWN/UP
25. REPEAT KEY/EQ KEY
26. LED LIGHT
7
20 19 18
22 21
