Operation
•
Before the first use, the luminaire must be charged for 5 hours.
The maximum battery capacity is achieved after 3 full charging
cycles.
Attention: During the charging process, keep easily flamma
ble objects away from the inspection lamp!
•
Charging process via 230 V charging cable
Connect the low voltage connector of the 230 V charging
cable to the charging socket of the lamp. The charging socket
is placed on the side of the lamp body. Afterwards, connect
the other end (Euro plug) with a 230 V socket. The control LED
shines red when the connection is successful.
•
Charging process via vehicle charging cable (12 V)
Connect the low voltage connector of the vehicle charging
cable to the charging socket of the lamp. The charging socket
is placed on the side of the lamp body. Afterwards, connect the
other end (vehicle charging plug) of the vehicle charging cable
with the 12 V cigarette lighter socket of your vehicle. The control
LED shines red when the connection is successful.
•
Charging process via charging tray
Connect the low voltage connector of the 230 V charging cable
with the charging socket of the charging tray. The charging
socket is placed on the side of the charging tray. Afterwards,
connect the other end (Euro plug) with a 230 V socket. Push the
LED inspection lamp sideways into the charging tray, so that the
charging socket of the lamp obtains contact with the charging
plug of the charging tray and locks. The control LED shines red
when the connection is successful.
•
In order to turn it on/off, press the on/off button
•
Magnet holder / suspension hook
At the back side of the inspection lamp, a suspension hook
with an integrated magnet is attached. You can attach the
inspection lamp to metallic surfaces via the magnet or hang
it with the help of the suspension hook. The suspension hook
can be folded out by turning it lightly.
•
Stand food
The stand foot is placed at the back side of the inspection lamp
and is clasped to the bottom. Unhook it at the bottom and
adjust the lamp to the desired position.
•
The rechargeable battery
For the optimal care of the integrated battery, avoid perma-
nent charging over the recommended charging time of 5 hours.
Deep discharge of the battery is to be avoided.
Attention / safety
1.
Do not look directly into the light. This can lead to temporary or
permanent eye damages. The manufacturer or the distributor
can not be held responsible for these injuries. Halten Sie die
Leuchte von Kindern fern.
2.
Keep the lamp away from children .
3.
The chargers have the IP code IP20 and may only be used
indoors in dry rooms.
4.
The inspection lamp has the IP code IP44 – splashwater-proof –
but should not be constantly exposed to splash water. Never dip
or operate the lamp under water!
5.
The NiMH battery is excluded from the warranty and may not be
removed from the lamp.
6.
At the back side of the inspection lamp, a strong magnet is
placed. Keep the lamp away from all devices and objects that
can be damaged by strong magnet fields!
Cleaning and care
1.
Before cleaning / care, the lamp must be disconnected from
the charger.
2.
In order to remove dirt, dust, oil, grease etc., use a soft cloth
lightly moistened with a mild soap solution or water. Afterwards,
dry it with a soft and dry cloth. Do not use any corroding subs-
tances or solvents for cleaning.
Warranty
With regard to warranty and guarantee regulati-
ons, the terms and conditions valid at the time of
purchase apply.
Take a look at our latest sites at www.setolite.com/en
Disposal
Your product is produced with high-quality materials
and components that are recyclable and can be used
again. This product must be disposed of separately from
the household waste. Please dispose of the product at
your local collection point or at the recycling centre.
Please help us preserve the environment we live in.
R
etuRning of old equipment
We take care of eco-friendly disposal of your old equipment, refer directly
to your Setolite team!
Technical Data
Type
LED inspection lamp
Illuminant
3 W LED (COB)
Light colour (white) approx.
6500 °K
Operating time approx.
3 hours
Battery
Li-Ion 3,7 V / 1800 mAh
Charging time approx.
5 h
Weight
200 g
Dimensions
190 x 60 x 45 mm
Charging time approx.
LED inspection lamp, charging cable
(230 V), vehicle charging cable 12 V,
charging tray
Item no.:
70__004015
