Quax COMBI Handbuch Seite 24

LOUISE
COMBI
Quax
First dreams
®
First steps
Step 3 - Changing the position of the bottom
Unscrew the base from the bottom supports. Unscrew slightly all connections of the bed, remove the bottom
from the bed and move the bottom supports to a new position at equal height. Replace the bottom and fi x it
back again to the supports. Retighten all bed connections.
Step 4 - Transition to junior bed
and fourteen wood screws I
Push the wooden dowels (F) in the provided openings of the bottom supports (6) and next the wood screws
(I). Hold these supports above the provided openings on the innerside of the long bed sides (5) and fi x the
woodscrews in the sides.
Step 5 : Use the parts of step 4, the wooden dowels G of step 1 and four eccentrics H1
Push the wooden dowels (G) in the provided openings at the ends of the long bed sides (5). Push the ec-
centrics (H1) in the provided openings left and right on the innerside of the bed sides.
24
Kinderbed met verstelbare bodem Doorgroeibed
54 01 34xx 01 01 43XX
KInderbett mit verstelbarer Boden Combi Bett
: Use both long sides 5, four bottom supports 6, eight wooden dowels F
Lit enfant avec fond réglable
Lit transformable
120/60-200/90
Babybed with adjustable bottom
120/60-200/90
120/60-200/90
Combi bed
120/60-200/90
