Alpha IP RC8 66001-xx
24

Displays

7 Displays
The LED of the system key of the device signalises the device status by
means of light and flashing patterns.
7.1

Status displays

Display Meaning
Long lighting in Process confirmed
green
1 lighting in orange Test indication
and 1 lighting in
green (after plugging
into a power outlet)
Short flashing, Teach-in mode active
orange (once every
10 seconds)
Long/short flashing, Updating the device
orange (alternately) software
7.2

Error indications

Display Meaning
Long lighting in red Transmission error,
transmission limit
reached (duty cycle)
DEU ENG
Meaning
Confirmation of per-
formed setting/trans-
mission.
Wait until the device
is ready.
Enter the last four
digits of the serial
number of the de-
vice.
Wait until the update
is finished.
Solution
• Re-send the command
after one hour at the
latest in case of ex-
ceeded duty cycle.
• Check the device for
defects,
• e. g. mechanical
blocking.
• Eliminate radio inter-
ference.
