ARCHOS Mini-Cam

Description of the Mini Cam
Pairing button
1
Pairing indicator
2
Camera lens
3
Microphone
4
Sticker
5
When you long press
the Pairing button
(5 seconds)
When you do a short
press on the Pairing
button
4
UserGuide_ARCHOS_Smart_Home_Tablet_book.indd 4
Putting into service the Mini Cam
Your camera functions with 3 Lithium cell CR 24 50
batteries.
1. Unscrew the camera ball.
2. Remove the insulation label "remove before use".
3. Screw back up.
4. Place the camera on its stand.
Magnets keep it stable. You can move the camera to
point in any direction.
5. Remove the sticker on the stand to stick the device to
a wall or ceiling.
LED blinks for 60 seconds
LED blinks for 10 seconds
LED blinks 3 times
LED is ON for 5 seconds
LED blinks fast
The device is in pairing mode and is
trying to connect to a tablet.
The device is already paired but is
disconnected. It tries to connect.
The device is unpaired and disconnected.
The device is paired and connected.
An over-the-air update is occuring.
