1A-PROGRAMMING SIMPLEBUS COLOR MODE
1 JP1 to ON
2 ALL S2 dip switches to ON
3 1 to 7 to OFF
4 dip switch 8 of S1 to OFF
5 red LED is flashing intermittently and rapidly.
6 P1 button
PROGRAMMING THE BRANCH ADDRESS RANGE
1 JP1 to ON
2 ALL S2 dip switches to OFF
3 S1:
4 Set the minimum range value:
S1:
dip switch 7 to OFF
S2:
MIN user address
5 P1 button
EXAMPLE: USER ADDRESS 3 ON BRANCH OUTPUT 1
6 Set the maximum range value:
S1:
dip 7 to ON
S2:
MAX user address
7 P1 button
EXAMPLE: USER ADDRESS 33 ON BRANCH OUTPUT 1
8
9 JP1 to OFF
MANUAL PROGRAMMING RESET
1 JP1 to ON
2 ALL S1 dip switches to ON
8 8
PROGRAMMING
yellow DL8 LED flashes once
ON
OFF
yellow DL8 LED flashes once
ON
OFF
MIN
yellow DL8 LED flashes once
ON
OFF
MAX
1B-PROGRAMMING SIMPLEBUS COLOR TOP MODE
1 JP1 to ON
2 ALL S2 dip switches to ON
3 1 to 7 to OFF
4 dip switch 8 of S1 to ON
5 red LED is flashing intermittently and rapidly.
6 P1 button
PROGRAMMING THE ZONE ADDRESS RANGE
1 JP1 to ON
2 ALL S2 dip switches to OFF
3 S1:
4 Set the minimum range value:
S1:
dip switch 7 to ON
8 to OFF zone addresses between 1 and 250
ON zone addresses between 251 and 500
S2:
MIN zone address
5 P1 button
EXAMPLE: ZONE ADDRESS 100 ON BRANCH OUTPUT 4
6 Set the maximum range value:
S1:
dip 7 to ON
dip 8 to OFF zone addresses between 1 and 250
ON zone addresses between 251 and 500
MAX zone address
7 P1 button
EXAMPLE: ZONE ADDRESS 450 ON BRANCH OUTPUT 4
8
9 JP1 to OFF
1C-PROGRAMMING USING HAND-HELD PROGRAMMER ART. 1251/A
(WITH R.I. OF 009 OR GREATER)
1
2 JP1 to ON
3
4 JP1 to OFF
lit steadily
3
+ 5 flashes of the red LED
4 JP1 to OFF
yellow DL8 LED flashes once
ON
OFF
yellow DL8 LED flashes once
1-250
ON
OFF
MIN
yellow DL8 LED flashes once
251-500
ON
OFF
MAX
red LED
yellow LED flashes once
