white
red
Inductor
Inductor
white
red
Install the screw clamp into the inside so that it does not touch the steel plate of the
screw cap (B); the same applies to the cables. Or the sound release is disturbed
(only a clatter or similar can be heard).
Use a small screw clamp.
• Place the power cord on the outside according to current safety regulations; dependent on
the usage site. Use e.g. plastic cables, where the power cord can be fixed.
Attention!
If the signal siren is installed freely accessible, an expert must make sure that the
screw cap (B) cannot be opened without using a tool.
Or parts are exposed after removing the screw cap and the supply voltage there is
a danger through an electric shock!
If necessary, e.g. a plastic screw can be screwed on one side into the cover or the
screw cap is to be pasted over.
• If it is connected to the supply voltage, the signal siren makes a loud sound.

Care and cleaning

• Disconnect the product from the power supply before cleaning.
• Do not use any aggressive cleaning agents, rubbing alcohol or other chemical solutions as
they can cause damage to the housing and malfunctioning.
• Clean the product with a dry, fiber-free cloth.
• Dust can very simply be removed with a soft, clean brush and a vacuum cleaner.
• Do not immerse the product in water.
Disposal
Electronic devices are recyclable waste and must not be disposed of in the
household waste. At the end of its service life, dispose of the product according to
the relevant statutory regulations.
You thus fulfil your statutory obligations and contribute to the protection of the
environment.

Technical data

Supply voltage .............................. 230 V/AC, 50 Hz
Power input ................................... 8 VA
Signal frequency ........................... 100 Hz
Acoustic pressure ......................... 85 dB/1m
Max. on-time ................................. 10 minutes
Cooling time .................................. 10 minutes
Storage temperature ..................... -20 to +70 °C
Operating temperature ................. -10 to +50 °C
Humidity ........................................ max. 90 % rel. humidity, not condensing
Dimensions (Ø x H) ...................... 85.7 x 44.4 mm
Weight .......................................... ca. 162 g
Screw clamp
Screw clamp
Supply voltage
Supply voltage
230 V~
230 V~
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the
capture in electronic data processing systems require the prior written approval by the editor. Reprinting, also in
part, is prohibited. This publication represent the technical status at the time of printing.
Copyright 2018 by Conrad Electronic SE. *1662136_V2_0418_02_mxs_m_en
