U
NIVERSAL SUSPENSION SKIMMER
Instruction for assembly and use
Package Contents (Figure A)
1)
Pool hook with inflatable lime (with diameter
ca 150 – 240 mm)
2)
Skimmer holder
3)
Adjustable bar
4)
Float
5)
Skimmer basket
6)
Skimmer basket
7)
Flap
8)
Skimmer body
9)
Adapter universal
10) Hose (d 32 mm – ca 70 cm)
11) Clamp
12) Screw
13) Washer
14) Fixed frame pool hook (with diameter ca 35 –
45 mm)
15) Adapter Intex
Safety instructions
Read and follow all these safety guidelines.
WARNING: To prevent accidents, disable any
manipulation of this product with children. Only
adults may install and disassemble this product.
Prior to assembly, disassembly and cleaning, always
switch off the filter pump first.
Before using the pool, turn off the filter pump and
remove the skimmer.
Keep your hands, hair close to the skimmer intake
during operation ‐ there is a risk of trapping.
RECOMMENDATION: Before covering the pool with a
tarpaulin, please remove the product from the pool.
Please check all components before use. When
storing the product, store it in a dry place indoors.
Mounting instructions
1. Assemble the holder first ‐ according to the pool
type:
a. For pools with inflatable collars, use Parts 1,
2, 3, Figure 1.
b. For fixed frame pools, use Parts 12, 13, 14, 3 ‐
Attach the washer 13 and screw 12, Fig. 1 to
the hook 14.
2. Attach the hose 10 (clipped hose section) to the
skimmer body, figure 2.
3. Attach the skimmer hose to the wall, use the
appropriate adapter 9 or 15, Figure 3.
4. Connect the whole bracket assembly to the
skimmer, Figure 4.
5. It is necessary to hold the clamp 11 when the
holder is inserted, figure 5. The skimmer must be
immersed in water 2‐3 cm. You can adjust the
height by pressing the clamp and sliding the
bracket.
6. Insert a skimmer basket and float into the
skimmer body, Figure 6. The float must swim
above the skimmer at a distance of 2.5 cm to 12.7
cm. The skimmer surface must always be in
vertical position so that the top of the float is
parallel to the water surface and the skimmer can
collect the dirt well.
7. Filter the filter device according to the user
manual for filtering, figure 7. Turn on or plug into
a power socket. If water does not flow into the
filter device, make sure the skimmer is
perpendicular to the water surface and immersed
under water. Open the air escape valve on the
filter and as soon as the water starts to flow, close
the valve. Never let the filter device run without
water. The pump may overheat and damage may
occur.
Warranty conditions
The skimmer was made of the highest quality materials
and high quality finish. All parts have been inspected and
found to be unsafe. The warranty is valid for two years
from the date of purchase. Keep all purchase documents
together with the instructions. Proof of purchase will be
required when applying warranty claims.
Complaints of goods are governed by the legal order. The
warranty covers all defects caused by manufacturing faults
or material defects affecting the functionality of the
skimmer.
After purchasing the skimmer, we recommend checking
the integrity of the shipping container and skimmer or
other degradation. In the case of any damage the dealer
immediately. We recommend that you review its
completeness when purchasing the product.
If the skimmer shows obvious defects that occur
immediately after commissioning and for which the
skimmer cannot be used, the buyer must apply defects to
the seller without undue delay. If a fault is detected on the
individual parts of the skimmer, complain only that the
defective part with the visible location of the damage is
damaged. The warranty does not apply to wear due to
improper installation or incorrect use, improper handling,
wear and tear of equipment corresponding to the nature
and time of its use, defects caused by mechanical damage,
defects caused by natural forces, defects caused by the use
of non‐standard means for chemical maintenance of pool
water and inappropriate cleaning aids, use of non‐original
parts, unauthorized interference skimmer or its damage.
Changes and print errors are reserved.
