2. Installation

This chapter will guide you through the whole installation process of STB. Please read each section carefully to make
sure that the system runs properly.
1. Connecting Satellite Cables
STB is integrated with two satellite tuners, and the first step is to connect the satellite cable(s) to STB. In order to
gain optimal signal quality, you can choose either of the following connection methods depending on the equipment
you have.
A. Two Separate Satellite Cables
In case you have two separate satellite cables providing different broadcast signals, you can configure LNB 1
Input and LNB 2 Input independently.
2. Connecting the TV
STB provides a variety of audio/video connection methods.
A. Connecting TV via HDMI cable
For the sake of the best picture quality, especially for digital TV, HDMI connection is recommended. Most HDTVs
have HDMI connectors to ensure the highest picture quality. In the rear panel of STB has a HDMI connector for
this purpose. Connect your TV to STB using a HDMI cable as follows.
B. Connecting TV via Component Cable
The second recommend TV connection for digital TV is via component cable (YPbPr). However, unlike the HDMI
connection which delivers audio and video signal at the same time, YPbPr connection requires additional audio
connection either via RCA cable (Stereo L/R) or S/PDIF as follows.
C. Connecting TV via RCA (Video) Cable
STB provides Composite video connection as well. Composite cable has normally three connectors at the both
end; one Video (Yellow) and two Audio (White / Red). Connect your TV to STB as follows:
7
