Danger!
When using the equipment, a few safety pre-
cautions must be observed to avoid injuries and
damage. Please read the complete operating
instructions and safety regulations with due care.
Keep this manual in a safe place, so that the in-
formation is available at all times. If you give the
equipment to any other person, hand over these
operating instructions and safety regulations as
well. We cannot accept any liability for damage
or accidents which arise due to a failure to follow
these instructions and the safety instructions.

1. Safety regulations

Danger!
Read all safety regulations and instructions.
Any errors made in following the safety regula-
tions and instructions may result in an electric
shock, fi re and/or serious injury.
Keep all safety regulations and instructions
in a safe place for future use.
General notes
1. Read the directions with due care. Familiarize
yourself with the settings and with the proper
use of the attachment.
2. Also be sure to observe the safety instruc-
tions and the operating instructions of the
basic unit required for operation.
3. If you give the equipment to any other person,
give them these operating instructions as
well.
Preliminary measures
1. Wear non-slip shoes when clearing snow.
2. Prior to using the equipment, visually inspect
it to ensure that the clearing blade, skids and
the mounting bolts of the snow plow blade
are in good working order (i.e. not worn out or
damaged).
Handling
1. Make sure that the snow plow blade is moun-
ted in accordance with the operating instruc-
tions.
2. When using the snow plow with snow chains
observe the information supplied by the ma-
nufacturer and ensure suffi cient clearance
between the machine components.
3. When swiveling the snow plow blade, look out
for crushing and shearing points.
4. The working speed must be adjusted to the
relevant work conditions.
GB
Maintenance and storage
1. Make sure that all nuts, bolts and screws are
tightened securely and that the equipment is
in a safe working condition.
2. For your own safety, replace worn or dama-
ged parts without delay.
2. Layout and items supplied
(Fig. 1-4)
2.1 Parts for the support frame (Fig. 2)
1 Support frame (right)
2 Support frame (left)
3 8x screw M8x40
4 1x screw M8x50
5 2x nut size M8
6 9x circlip Ø8mm
7 10x washer Ø8mm
8 8x washer Ø10mm
9 1x special nut
10 1x washer for special nut
11 Mounting lugs for snowplow blade
12 Hook holder for lever (raising/lowering)
2.2 Parts for the blade (front) (Fig. 3)
13 Snowplow blade
14 1x clearing bar
15 1x counter pressure bar
16 6x lock bolt M8x35
17 6x nut M8
18 6x circlip Ø8mm
19 6x washer Ø8mm
2.3 Parts for the blade (rear) (Fig. 4-5)
20 Swivel frame
21 Bolt for swivel frame
22 Washer for swivel frame
23 Split pin for swivel frame
24 Swivel segment
25 Washer for swivel segment
26 Split pin for swivel segment
27 Lever for raising/lowering
28 Extension for lever (raising/lowering)
29 Fixing screw for lever (raising/lowering)
30 Split pin for lever (raising/lowering)
31 Lever for angle adjustment
32 Fixing screw for lever angle adjustment
33 Bolt for attachment of the snowplow blade to
the support frame
34 2x split pin for bolts for attaching the
snowplow blade
