Product Outlook

Display screen
Function softkeys
To perform the func-
tion displayed above
each softkey.
Acquisition and func-
tion controls
To access the scope,
meter, logger, system,
and help functions.
Power key
Horizontal controls
To control the sweep speed (sec/div)
and horizontal position of the wave-
form. Use
to zoom into the waveform.
U1610/20A Quick Start Guide
U1610/20A Handheld Digital Oscilloscope
Scope terminals
Meter terminals
USB interface
connector and
DC power inlet
Directional keys
Vertical controls
To set the vertical
scaling (volt/div)
and vertical offset.
3
