3.4. Multi-function

Depending on the input switches on the MPA R (29, 31, 33, 34, 36, 38, 39, 41, 43) located on the
rear panel, four different amplification configurations can be achieved:
MPA4-80R
- 4 mono amplifiers with following possibilities:
4 different mono inputs
1 common mono input for all
1 common stereo input for all
- 2 stereo amplifiers with following possibilities:
2 different stereo inputs
1 single stereo input for both
- 2 bridged amplifiers with following possibilities:
2 different mono inputs
1 common mono input
1 common stereo input
- Combinations between mono, stereo and bridged
MPA6-80R
- 6 mono amplifiers with following possibilities:
6 different mono inputs
1 common mono input for all
1 common stereo input for all
- 3 stereo amplifiers with following possibilities:
3 different stereo inputs
1 single stereo input for both
- 3 bridged amplifiers with following possibilities:
3 different mono inputs
1 common mono input
1 common stereo input
- Combinations between mono, stereo and bridged
7
