Important Safety Instructions
Contents
Important Operational Instructions
Detail of Parts
Flush Mount Cup Installation
Angle Mount Cup Installation
Diagram of Connections and Cable Preparation
Attention: Important Operational Information. Please Read Before Installation.
The loudspeakers may only be operated with the indicated nominal power and only with the enclosed
crossovers or with the recommended high-pass and low-pass frequencies and slopes
Any operation without the enclosed crossovers or with frequencies and slops other than the
recommended may cause damage to the loudspeakers
Exchanging the "woofer" and "tweeter" terminals on the crossover, may destroy tweeters immediately
Do not open the the tweeter housing as this may destroy the tweeter
When connecting loudspeakers, crossovers , and amplifiers ensure polarity is the same throughout.
Exchanging of the polarity produces an unnatural sound that lacks in bass power
For reasons of technical safety, use only the enclosed screws to fasten the loudspeakers. If you fasten
them with any other materials, we do not accept any liability.
2 pieces
Tweeter DL-T20 (Part-No. 241302)
2 pieces
Crossover (231090 only / Part-No. 252007)
2 pieces
Tweeter stand Cup
2 pieces
Flush Mount Cup
2 pieces
Angle Mount Cup
1 piece
Installation Instructions
Mounting accessories
Contents
Contents and Details of Parts
13
2
3
3
3
4
4
5
5
Figure 1
5
Figure 2
6
Figure 3
6
7
7
Figure 4
8
8
