Rear Suspension
Hintere Aufhängung
T02029 4.8mm Ball End(Long)
Kugelpfanne (lang)
..............................4
T02091 3x54 Adjust Rod
Gewindestange
..............................2
24
Rear Suspension
Hintere Aufhängung
25
Main Chassis
Chassis
T02083 M3x8 Screw
Schraube
............2
T02083 M3x10 Screw
Schraube
............2
x2
Assemble as many times as specified
So of montieren wie angegeben
T02029
T02093
T02093
T02083(3x10)
T02025
T02025
T02025
1:1
True-to -scale diagram
1:1 Größe
Projection.Note direction
Hinweis Richtung
approx.35mm
circa.35mm
T02083(3x8)
12
Rear Upper
Hinten oben
x2
T02029
T02091
T02093
T02093
T02083(3x10)
1:1
T02025
