7
Front Suspension
Vodere Aufhängung
T02029
T02091
T02029 4.8mm Ball End(Long)
Kugelpfanne (lang)
............8
T02091 3x54 Adjust Rod
Gewindestange
8
Front Suspension
Vordere Aufhängung
T02093
T02093
9
Front Suspension
Vordere Aufhängung
T02082(M3x22)
T02063
T02082(M3x10)
x1
Assemble as many times as specified
So oft montieren wie angegeben
T02029
.........4
T02092
T02082(M3x22)
T02063
T02082 M3x22 Screw
T02020
1:1
True-to -scale diagram
1:1 Größe
Projection.Note direction
Hinweis Richtung
approx.38mm
circa.38mm
Projection.Note direction
Hinweis Richtung
approx.38mm
circa.38mm
Projection.Note direction
Hinweis Richtung
approx.34mm
circa.34mm
T02093
T02092
T02082 M3x10 Screw
Schraube
......2
4
Front Upper(Right)
Vorne oben (rechts)
x1
Front Upper (Left)
Vorne oben (links)
x1
Steering Tip
Lenkung
x2
T02093
T02093
T02063 5mm Ball stud
Schraube
Kugelkopf
.........4
...............2
1:1
1:1
1:1
