Technical Data - CleanMax Z 09623 Gebrauchsanleitung

Problem
The suction power is weak.
The device emits dust
when vacuuming.
The control light doesn't
illuminate when the device
is connected to the mains
supply.

Technical data

Device
Model number:
Product number:
Voltage supply:
Output:
Rechargeable battery
charging time:
operating time:
Mains adapter
Model number:
Input:
Output:
Safety class:
Charging station
Input:
Output:
21
Possible cause/solution
• Is the waste water tank full? Empty the bin.
• Is the fi lter heavily laden with dirt? Clean it.
• Is the suction opening plugged?
Turn off the device and remove the blockage.
• It is also possible that some particles remain caught
in the carpet fl oor or that they are too large/too
heavy for the device to vacuum up. Simply remove
the debris by hand.
• Check whether the dust bin and fi lters have been
properly inserted and if necessary, correct their
seating.
• Is the mains adapter properly connected with the
socket and the barrel connector with the connector
jack on the device?
• Is the socket defective? Try another socket.
• Check the fuse for your mains connection.
PC-P008
Z 09623
14.8 V (Li-ion 2000 mAh)
100 – 120 W
approx. 4 – 5 hours
approx. 15 – 18 minutes
(when fully charged)
XS-180050EU
100 – 240 V ~ 50/60 Hz
18 V DC, 500 mA
II
18 V
14,8 V
Customer service/
Importer:
DS Produkte GmbH
Am Heisterbusch 1
19258 Gallin
Germany
Tel.: +49 38851 314650
(Calls to German landlines are
subject to charges. The cost
varies depending on the service
provider.)
EN
