THE REMOTE CONTROL
ATTENTION
Open compartment and
remove safety tab prior to use.
MOUNTING INSTRUCTIONS
TROUBLESHOOTING
PROBLEM:
I can't hear any audio.
The unit is not turning on.
The remote control is not working.
My iPod does not fit well in the dock.
SPECIFICATIONS
Dimensions:
Weight:
Audio Outputs:
Inputs:
Power:
Accessories:
FOR TECHNICAL SUPPORT AND ADDITIONAL INFORMATION ABOUT THIS PRODUCT, VISIT
The remote control offers a quick way to access the unit's most
essential playback functions from a distance.
1.
>|| - This button functions as the '>||' button of your iPod.
2.
|<< - This button functions as the '|<<' button of your
iPod.
3.
>>| - This button functions as the '>>|' button of your
iPod.
This device may be mounted in a standard 19" rack taking up
2 spaces. Please use 4 rack screws (not included) to secure
the unit to the rack.
3.5" (H) x 19" (W) x 4.7" (D)
3.775 lbs
Balanced XLR
Unbalanced RCA (x2)
4G iPod and later (with dock connector)
AC IN, 100 ~ 240V
50/60 Hz, 17W
Stereo RCA Cable (x2)
Software CD
Quickstart Manual
Remote Control
Power Cable
Safety and Warranty Information
SOLUTION:
Check to make sure that your iPod is playing.
Make sure that the unit is powered on.
Make sure that the unit's audio outputs are connected to a speaker or
amplifier system and that the system is turned on.
Make sure that the power cable is connected to the rear of the unit and
that it is plugged into a live power source.
Make sure that the safety tab in the remote control's battery
compartment is removed prior to using the remote.
Use the iPod Universal Dock which was included with your iPod.
RCA outputs:
Output Level: 8.2dBv +/-1dBv
THD: Less than 0.01%
S/N Ratio: Better than 85dBr
Frequency Response: Flat within 2dB from 20Hz to
20kHz
XLR outputs:
With trim set to 0dB:
Output Level: 22.5dBu +/- 1dBu
THD: Less than 0.01%
S/N Ratio: Better than 85dBr
Frequency Response: Flat within 2dB from 20Hz to
20kHz
3
WWW.NUMARK.COM
