Helios Ventilatoren BEDIENUNGSANLEITUNG OPERATING INSTRUCTIONS Mischgas-Fühler für easyControls Mixed Gas Sensor for easyControls KWL-VOC zur Erfassung der Mischgas-Konzentration for measuring mixed gas concentrations...
Wenn die nachfolgenden Ausführungen nicht beachtet werden, entfällt unsere Gewähr- leistung. Gleiches gilt für Haftungsansprüche an den Hersteller. Der Gebrauch von Zu- behörteilen, die nicht von Helios empfohlen oder angeboten werden, ist nicht statthaft. Even tuell auftretende Schäden unterliegen nicht der Gewährleistung.
Bedienungsanleitung Mischgas-Fühler KWL-VOC für easyControls Stromaufnahme 32 mA bei 24 V DC Anschlussmögl. bis zu 8 Stück Steuerleitung SL 4/3 (3 m lang) Umgebungstemperatur 0 - 40 °C Messbereich VOC 450-2000 ppm Belastbarkeit Analogausgänge max. 20 mA Kabelquerschnitt Federzugklemme Ø 0,75 mm mit Aderendhülse Ø...
Seite 4
Stoffen (z.B. Lacke, Lösungsmittel, Klebstoffe) oder die Zubereitung von Speisen. Durch die notwendige Initialisierungsphase dauert es ca. 15 Minuten bis sich das Steuer- signal des KWL-VOC qualitativ auswerten lässt. In dieser Phase sollte der Mischgas-Fühler frischer Luft ausgesetzt sein, da dieser Wert als Referenz genommen wird. Wenn die Versor- gungsspannung kurz unterbrochen wird, benötigt der Mischgas-Fühler eine Initialisierungs-...
Seite 5
Bedienungsanleitung Mischgas-Fühler KWL-VOC für easyControls 4. Schaltplan SS-1075...
Our warranty shall not apply if the following instructions are not observed. The same applies for liability claims against the manufacturer. The use of accessories, which are not recommended or offered by Helios, is not permitted. Any damage that may occur is not liable for warranty.
Operating Instructions Mixed Gas Sensor KWL-VOC for easyControls Power consumption 32 mA at 24 V DC Connection options up to 8 units Control line SL 4/3 (3 m long) Ambient temperature 0 - 40 °C Measuring range VOC 450-2000 ppm Load capacity Analogue outputs max.
Seite 8
Operating Instructions Mixed Gas Sensor KWL-VOC for easyControls 3. Use of analogue outputs Connection of mixed gas sensor KWL-VOC to a ventilation unit (KWL unit, fan etc.), which is equipped with an analogue input (0-10 V). Note polarity! Please note:...
Seite 9
Operating Instructions Mixed Gas Sensor KWL-VOC for easyControls 4. Wiring diagram SS-1075...
Seite 10
Operating Instructions Mixed Gas Sensor KWL-VOC for easyControls...
Seite 11
Operating Instructions Mixed Gas Sensor KWL-VOC for easyControls...
Seite 12
