axing basic-line SAA 80-01 Betriebsanleitung Seite 3

Safety advices:
 Prior to the installation of this parabolic aerial, it is essential that
these safety instructions are observed! Failure to comply with these
instructions may result in injury or even death. The manufacturer is not
liable in case of improper installation and connection errors.
 Under no circumstances may the antenna be installed under or in close
proximity to overhead power lines! A minimum lateral distance of >1
m from any electrical equipment must be observed. Touching electrical
installations may cause death!
 Never work on antennas during thunderstorms or when a thunderstorm
is approaching. There is a risk of death!
 Never install antennas on buildings with inflammable roof coverings
such as in thatched roofs! In such cases there is a fire hazard due to
atmospheric surge voltages (static electricity) or lightning (e.g. during
thunderstorms).
 The installation procedure described herein requires good technical
skills and knowledge on properties of materials when exposed to wind.
Therefore, have the work executed by a trained technician in case you do
not have these skills yourself.
 The person executing the installation must wear sturdy antislip-footwear,
should have no fear of heights, be able to move safely on the roof
and have a secured standing and holding position (e.g. by using belts
connected to the roof).
 Check whether the roof can support your weight. Never step on cracked
or non-load-bearing areas! If in doubt, consult a qualified dealer or
roofing craftsman to determine a suitable installation position.
 Enter roofs or areas with a risk of falling only with a safety harness that
is properly worn and free of defects or use a work platform.
 Ladders or other climbing aids must be in good order and condition (dry,
clean and slip-resistant).
 If there is a possibility that there may be a hazard to pedestrians due to
falling objects during installation, you must block the hazard zone! Make
sure that there are no persons present below the location of installation.
 Falling from or through the roof and falling parts can cause death and
significant material damage. The manufacturer cannot be held liable for
such damage.
 The applicable national safety regulations and current standards such as
DIN EN 60728-11 must be observed.
State of the art 2018-06-20
Technical improvements, changes in design, printing- and other errors expected.
Technical data:
Article SAA 80-01
Reflector dimensions
Mast diameter
Diameter of feed
Frequency range
Antenna gain
Full width at half maximum
Wind load up to 20 m mounting high
Elevation range
Reflector material
Colour grey
Herewith AXING AG declares that the marked products comply with the valid
guidelines. You can call up the complete EU declaration of conformity for
download by entering the article in the search field at www.axing.com.
WEEE Nr. DE26869279 | Electrical and electronic components must not be
disposed of as residual waste, it must be disposed of separately.
Manufacturer EEA contact address
AXING AG Bechler GmbH
Gewerbehaus Moskau Am Rebberg 44
8262 Ramsen 78239 Rielasingen
SAA 80-02 SAA 80-03
SAA 80-0x
85 x 75 cm
32...60 mm
40 mm
basic-line
10,75/11,75/12,75 GHz
37 dB Aluminium
< 2,2°
325 Nm
satellite antennas
16...50°
Aluminium
85 x 75 cm
anthracite brick-red
Operation instructions
