Formech 508 DT Aufstellungs-, Bedienungs Und Wartungsanleitung Seite 55

508DT & FS Hauptkomponentenliste
Anzahl Beschreibung
1 Vacuum filter Cartridge (508FS)
1 5/2 Valve 24Vdc 6W
1 2/2 Air Valve 1/2"
1 2/2 Vac Valve 1/2"
1 40mm Vacuum Panel Mount Gauge
1 1/4" Bore PVC Reinforced Hose (508DT)
1 3/8" Bore PVC Reinforced Hose
2 1/4" BSPT to 10mm Hose Tail Elbow (508DT)
1 1/4" BSPT to 10mm Hose Tail Straight (508DT)
2 Pipe Clip - Small plastic, Type C, 1/4" Tube (508DT)
6 Pipe Clip - Small plastic, Type F, 3/8" Tube
2 Toggle Clamp Complete, Small Blue (508DT)
2 Small Clamp Upper Adjuster Nut Steel M5 (508DT)
2 Small Clamp Lower Adjuster Nut Plastic M5 (508DT)
2 Toggle Clamp (508FS)
2 Toggle Clamp Lower Nut Adjuster M6 Black (508FS)
2 Toggle Clamp Upper Nut Adjuster M6 (508FS)
2 Clamp Frame Grip
1 Crank Handle Grip
1 5M Seal kit, 5M Top Seal, 3m Table Seal, Sealant (Seal kit A)
1 10M Seal kit, 10M Top Seal, 3m Table Seal, Sealant (Seal kit B)
1 6mm x 12mm natural rubber Panel seal
1 Interlock Spring
4 Machine Rubber Mounting Foot
1 Mesh
Bedienungsanleitung - Formech 508DT/FS - Rev 3
55
Bezug
PAP15
P30
P05
P06
P31
P13
P14
P34
P36
P18
P37
MPP19
MPP27
MPP24
MPP20
MPP25
MPP28
GH44
GH24
SK02
SK03
MPP12
GH40
GH41
MPP46
