18
EN
Making this adjustment can also be done according to set methods. The rider
sits on the bike in the riding position. The cranks should be horizontal, The fore /
aft adjustment should be make until the knee cap of whichever leg is the leading
leg is directly over the pedal axle.
Fig 5: Knee cap method
Attention:
Do not clamp outside of
the marked area.
Fig 6: Fore / aft adjustment
ERGON BIKE ERGONOMICS

Saddle Angle

Generally speaking a saddle should be level. This prevents the rider slipping
forwards or backwards. It also prevents too much pressure being applied either
front or rear. It is also recommended that the saddle is completely straight in line
with the frame. This allows the rider to apply equal load to the widest part of the
saddle where the sit bones are supported. If the rider finds themselves sitting too
far forward, then the fore / aft adjustment should be adjusted accordingly, or tilt
the saddle back fractionally.
Fig 7: Saddle angle
0° Angle of inclination
in the center of the saddle
19
EN
