Description And Function; Intended Use - Fixpoint 77455 Bedienungsanleitung

Manual
Fixpoint
ATTENTION! Read the manual completely and carefully. It is part of the product
and contains important advices for correct implementing and use. Retain this
manual for availability when passing to other persons and if there are further
questions.
Content:

1 Description and Function

2 Intended Use

3 Parts Package
4 Notes on Safety
5 Implementing and Operating
5.1 Installation and Mounting
5.2 Mounting Control
5.3 Connecting the Power Supply
5.4 Adjusting the Lamp
5.5 Adjustment of the Hinged Bracket
5.6 Engaging
5.7 Using the Magnifier
6 Warranty and Liability
7 Changing the Lens
7.1 Models 77450/45271, 77455 and 77456
7.2 Model 77451
8 Care, Maintenance, Storage and Transport
9 Troubleshooting
10 Specifications
11 Notes on Waste Disposal
12 CE Declaration
1 Description and Function:
Your Fixpoint
- shadowless lighting of workspace with LED lamp and
- detailed magnification of small objects 1.75 times (3+12 dpt)
77451 and 77455
Magnifier Cover (open)
Magnifier
Hinged Bracket
Table Stand
2 Intended Use:
Your Fixpoint
only allowed to use it in dry interior rooms. Disregarding and non-compliancy of these
terms and of the Notes on Safety may cause massive accidents and damages to people
and things.
8
LED Lenslights
®
-Lenslight achieves the following functions:
®
-Lenslight is provided to lighten working space and to magnify objects. It is
®
77450/45271/45268 and
77456
Magnifier Cover (open)
Magnifier
Hinged Bracket
Clamp
