PRODUCT FEATURES

General
•
Integrated high power amplifier
•
MP3 Player
•
High efficient low-mid woofer
•
Line and mic input with Bass and Treble
Controls
•
Line output allows daisy chaining of additional
speakers
Recommended for
•
Bars
•
Restaurants
•
Small theatre
INPUT PANEL
1. Balanced input connector MIC (PDA-8A: 6.3mm Jack or PDA-10A XLR-6.3mm Jack)
2. Volume control for MIC
3. Line input for audio input source e.g. mixer, CD player, etc
4. Balanced XLR line input
5. Volume control for Line Input
6. Tone control Bass and Treble
7. Output connector (line out). For connection to a second active speaker box.
8. Clip indication. These LED will light up when amplifier are on max power. It can occur that these LED
will lit up now and then, this is not a problem. But if it lights up continually you need to adjust the volume
down, otherwise permanent damage to equipment might occur
9. Power Indication. This clear green indicator will light when the amplifier is turned on.
10. On/Off Switch: For switching the speaker on and off. Always adjust the volume down to its minimum
before switching this speaker on.
11. Mains Power Connector / Fuse. This main fuse secures the speaker against defects. Replace this only
with a fuse of same type and value.
MP3 PLAYER
A. DISPLAY: Shows MP3 information
B. USB/SD SWITCH: Use switch for playing
from USB stick or SD card
C. PLAY/PAUSE: Track play or pause mode
D. STOP: Track stop playing
E. REPEAT: Select All, Folder, One or Random
•
High power dynamic horn driver
•
Wide dispersion directivity horn
•
Stand mounting with 35mm pole socket
•
ABS scratch-resistant housing
•
Compact speaker system for easy transport
•
Karaoke
•
Fitness
•
Conference rooms
F. PREV: Play previous track
G. NEXT: Play next track
H. USB CONNECTION
For connection of a USB stick with MP3 files
I. SD CARD CONNECTION
For connection of a SD CARD with MP3 files
•
Small halls
•
Stage monitoring
