6

Start-up

6.1 Start-up
To start up the device, simply plug it into a socket outlet in the
indoor 230 V mains power supply.
Press the channel button to operate the actuator and check that
everything is in working order.
Simply press and release the button (within 4 seconds)
to control the actuator. Pressing and holding down the
button (for more than 4 seconds) will switch the actuator to
teach-in mode.
6.2

Teaching-in

Please read this entire section before starting the teach-in
procedure.
In order to enable communication between radio components, the
devices have to be taught-in to one another. To execute the teach-in
procedure, both of the devices to be linked must be in teach-in mode.
The radio chime with light flash does not have a special teach-in
button. It has one channel for the light flash and another for the
chime. To trigger both the chime and the light flash, a transmitter (e.g.
a door/window contact) would have to be taught-in
separately on both channels. To teach-in, proceed as follows:
• Press and hold down the channel button on the radio chime for at
least 4 seconds.
• The light flashes. To activate teach-in mode for the light flash chan-
nel, press (short keystroke) the channel button briefly at this point.
17
