Kerbl TrimProfi 18195 Betriebsanleitung

EN: IMPORTANT
• Connect the device to AC only.
• Pay attention to the nominal voltage rating.
• Children and persons needing care should only use the device under supervision.
• The device must not be used within 1 metre from the bath or shower or over a wash-hand basin fi lled with water.
• Remove the power plug before cleaning.
• Never immerse in water.
• The device and the mains cable must be checked regularly for damage.
• If damage is detected, do not putt the device into operation. Instead, consult a skilled electrician.
• If the clipping performance decreases, the blades have to be grinded. Please contact your dealer.
• Do not disassemble the clipper by yourself. Please contact your dealer.
TECHNICAL DATA
Type: 18195
Mains voltage: AC 220-240V
Watt: 20W
Rpm: I = approx. 2500 rpm/min.
Dimensions (W/H/L): approx. 50 x 50 x 250 mm
Weight, excluding cable: 0,48 kg
USING THE HAIR TRIMMER
• Apply a little oil to the cutter set. Retry every 10 minutes while clipping.
• Connect the mains lead to the mains supply.
• The device is switched on when the switch is pressed to I or II. The sometimes audible striking noise of
varying loudness is caused by the starting torque of the AC drive. This is normal and is not a device fault.
• After use switch off the device (switch 0) and pull out the mains plug.
OPERATION TO PLACE THE BLADE ASSEMBLY
With the unit plugged into a specifi ed AC electrical outlet, turn the control switch to the I or II position. Holding the blade assembly
by the sides, to keep fi ngers away from the cutting edge. Place the blade assembly back into position on the tongue. Press forward
to lock into place. For latching press snap switch.
TO REMOVE THE BLADE ASSEMBLY
Unplug the electric cord and turn the control switch to the O position.
Hold the unit in one hand. For unlatching press snap switch. Grasp the cutting end of the blade assembly and snap it back and
away from the clipper. Slide the blade assembly forward and up off the clipper.
REMOVING DIRT AND HAIR
Occasionally, dirt and hair will lodge between the blade and comb, forcing them apart and stopping the cutting action. Remove
the blade assembly, as described above.
Push the blade sideways from its position under the metal clip. Remove the dirt and hair. Then, slide the blade back into
position.
NOTE: There is no need to remove the screws on the tension spring when removing dirt and hair.
CLEANING AND GENERAL CARE
• Turn control switch to O position
• Always remove the power plug before cleaning.
• Never immerse the device in water.
• Clean the body of the device with a soft, damp cloth. Never use solvents of scouring agents.
• The cutting head should be oiled frequently in order to maintain is good cutting performance and thus ensure along service life.
Then allow the machine to run for several seconds.
CE-symbol/CE-conformity declaration
Albert KERBL GmbH herewith declares that the product/machinery described in these instructions conforms with the basic requirements and the
other relevant conditions of regulations 2004/108/EG and 2006/95/EG.
The CE-symbol stands for fulfi lment of the European Union guidelines.
The conformity declaration can be viewed at the following Internet address: http://www.kerbl.de
DISPOSAL IN EU COUNTRIES
Do not dispose of the appliance with domestic refuse. As part of the EU Directive governing the disposal of electric and electronic
appliances, the appliance is accepted free of charge by local waste collection points or recycling centers.
Correct disposal will ensure environment protection and prevent a potential harmful impact on people and the environment
II = approx. 3000 rpm/min.
Betriebsanleitung
DE
Manuel technique
FR
Operation Manual
EN
Technobase Marketing
84428 Buchbach • Felizenzell 9, Germany
Tel.: +49 8086 933-100 • Fax: +49 8086 933-500
20 W
AC 220-240 V
50 Hz
