Unpacking and Assembly
1. Place the boxes on the floor, making sure that the product labels are facing up, and carefully open the
packaging on the long side where it has been taped up, preferably using a pocket knife or kitchen knife
(similar to illustrations).
2. Remove the "Welcome to the Audio Physic" package and the accessories.
3. Carefully remove the loudspeakers, together with their protective foam pads, from the upright box. It is ideal
if two people carry out this step. Make sure that you do not touch the drivers when removing and handling the
loudspeakers as this may cause irreparable damage to the drivers.
4. Now remove the top foam cover and carefully slide down the protective foil.
5. In a next step, detach the loudspeaker from the protective foam cover at the bottom and place it carefully on the
floor. It is ideal if two people carry out this step.
6. In order to attach the spikes to the traverses, one person should slightly tilt the loudspeaker sideways enabling
a second person to easily screw the spikes into the designated inserts. Repeat the process on the opposite side.
7. Screw the caps with the integrated counter nuts onto the spikes.
8. Place the CODEX loudspeakers in their intended positions.
Now finely adjust the spikes so that the loudspeakers do not rock, shift or wobble. If you do not
of the spikes.
place the loudspeakers in a secure and stable position and they therefore rock, shift or wobble, this will have a
major effect on the sound. When the boxes are standing level and upright, you have set them up perfectly. The
enclosed spirit level will help you to finely adjust the loudspeakers (they are level when the bubble remains in
the inner circle). Use the lock nuts to again tighten the spikes. Roughly hand-tightening the nuts is sufficient.
9. Our CODEX models are fitted with a solid front panel without fabric when delivered from our factory. If you
wish, you can exchange this panel for the panel covered in fabric that is also enclosed with your loudspeaker
to suit your tastes. To do so, simply use your fingers to carefully lift off the fitted panel.
you do not touch the drivers when doing so.
panel in its position and softly push it in into place until it is flush with the loudspeaker cabinet. You do not
need to worry about any limitations or loss of sound details when using either of the panels.
Accessory Package
The accessory package can be
found on top of the loudspeaker
where it is safely stowed. First
remove the cardboard envelope
from the box. After that, the
loudspeaker can be easily
removed from the box. Make sure
that you do not touch or reach
into the drivers when removing
the loudspeakers.
Welcome Package
Owner`s manual,
warranty card and spirit level for
fine adjustment.
Make sure that you do no hurt yourself on the tips
Once you have removed the panel, place the fabric-covered
Please ensure that
