Control panel

DANCE
00 ROCK 1
01 ROCK 2
02 RAP
03 HOUSE
04 DANCE
05 FUNK 1
06 FUNK 2
07 FUSION
ETHNIC
48 DANGDUT
49 KERONKONG
50 TROT
51 ENKA
52 TURK 9/8
53 BALADI
54 MALFOUF
55 NEW SAIDI
VOLUME
1
1. Volume. Regulates the General Volume. The regulation is propor-
tional to the individual volume settings of each sound section.
2. Manual Controls. Groups of buttons which control the Rhythms
and Automatic accompaniment. [START/STOP] starts or stops the Style
(or Song). [TOUCH START/CONTINUE] starts the Style when you play
a note or a chord in the Lower section (or starts the Song playback
from its current position). [INTRO/END] starts and stops the Style with
an introduction or an ending. [TAP TEMPO] starts the Style after beat-
ing time on the button. [FILL BASIC] triggers the Fill In and/or returns
to the Basic Style. [FILL VAR] triggers the Fill variation and activates a
variation of the Style.
3. Automatic Styles. [VARIATION] activates/deactivates the varia-
tion of the Style. [ARRANGE] activates/deactivates the automatic ar-
rangements.
4. Lower Section. Controls of the Lower section of the keyboard.
[SPLIT] activates/deactivates the split point between the Upper and
Lower sections. [LOWER] activates/deactivates the Lower section.
4
17
BEAT ROCK'n
08 8 BEAT1 16 BOOGIE
09 8 BEAT2 17 ROCK'n
10 8 BEAT3 18 TWIST
11 8 BEAT4 19 CHARL.
12 16 BEAT1 20 SLOW R.1
13 16 BEAT2 21 SLOW R.2
14 16 BEAT3 22 BALLAD1
15 16 BEAT4 23 BALLAD2
POP CD STYLES
56 POP 1 64 FUNK 1
57 POP 2 65 FUNK 2
58 POP 3 66 BEAT 1
59 POP 4 67 BEAT 2
60 SOUL 68 CANTALP
61 BLUES 69 SEXYMF
62 ROCK'n 2 70 MOTOWN
63 SWING 4 71 CARWASH
MANUAL CONTROLS
TOUCH START
START
CONTINUE
STOP
max
TAP FILL
TEMPO BASIC
min
2
JAZZ LATIN FOLK
24 SWING 1 32 BOSSA 40 WALTZ 1
25 SWING 2 33 SAMBA 41 WALTZ 2
26 SWING 3 34 LATIN 42 MARCH
27 FOXTROT 35 SALSA 43 POLKA
28 BIG BAND 36 CHACHA 44 BAROQUE
29 SHUFFLE 37 RHUMBA 45 COUNTRY
30 J.WALTZ 38 MAMBO 46 BEGUINE
31 DIXIE 39 TANGO 47 REGGAE
CD STYLES CD STYLES CD STYLES
72 SOUL 1 80 ROCK 1 88 HOUSE 1
73 SOUL 2 81 ROCK 2 89 HOUSE 2
74 SOUL 3 82 REGGAE 1 90 RnBLUES
75 SOUL 4 83 REGGAE 2 91 HIP-HOP 1
76 SOUL 5 84 DANCE 1 92 HIP-HOP 2
77 SOUL 6 85 DANCE 2 93 HIP-HOP 3
78 RAP 1 86 DANCE 3 94 HIP-HOP 4
79 RAP 2 87 HEAVY 95 BROWN
LOWER SECTION
INTRO
END
SPLIT
FILL
VAR
VARIATION
AUTOMATIC STYLES
3
5. [STYLES] and [SOUNDS] buttons. [STYLES] predisposes the
keypad for Style selection. [SOUNDS] predisposes the keypad for
Sound selection. Pressed together they act as an [ESC] function that
cancels certain edit situations and allows you to escape from Song
"record" mode and from MIDI and DELETE programming modes.
6. Keypad. Inserts numbers and letters. When the [STYLES] LED is
on, the keypad selects Styles, when the [SOUNDS] LED is on, the
keypad selects Sounds for the Upper section; if you press [LOWER]
when this LED is on, the keypad selects Sounds for the Lower section.
7. [PAGE] buttons. In MIDI mode these buttons pass to the previous
edit page or the next. When the LED of the [SOUNDS] button is on,
these buttons scroll through the Sound bank. When the LED on the
[STYLES] button is on, these buttons scroll through the Style bank.
Pressed together they select a different Sound Bank (Sound Bank 1 or
2).
8. [TEMPO-DATA] buttons. These allow you to change the playing
speed (Tempo) of the Styles. Press the buttons together to set the
18
TEMPO STYLES
ESC
1 2
ABC DEF
4 5
JKL MNO
7 8
LOWER
STU VWX
0
PAGE NAME
ARRANGE
4 5 6 7
SOUNDS
3
GHI
6
PQR
9
YZ_
PAGE
8
