on tour
Easy Setup Guide
Step 2.
Open battery compartment
Step 1.
Unpack on tour, wall adaptor and
by sliding button as shown. Battery
cable. Read this instruction sheet completely.
door will open.
Troubleshooting
on tour specifications
Symptom
Frequency range: 100Hz–20kHz
No sound from on tour
Power consumption: 6 W maximum
speaker system.
Transducers: (2) 1-inch full range per channel
Amplifier output power: 3 Wrms per channel
Dimensions:
6.75" (17.1 cm) long
3.5" (8.9 cm) wide
1.5" (3.8 cm) tall
Weight: 1.1 pound = 0.5 kg
Battery
Size - AAA
Type - Alkaline, NiMh, Nicad
DO NOT MIX BATTERY TYPES
DO NOT MIX CHARGED AND
PARTIALLY CHARGED
BATTERIES
BATTERIES WILL NOT
RECHARGE WHILE IN
SOUNDPOD
If you have any questions, or need further assistance, please visit www.JBL.com.
*These specifications are subject to change without notice.
6
Step 3.
Place (4) fresh AAA batteries
Step 4.
Open protective cover by
as shown. Replace battery compart-
sliding cover as shown. When the
ment cover. System will function with
cover is closed, the system will
AC power only or batteries.
power off.
Possible problem
Solution
No power to system.
Ensure power supply is connected to live
power source and properly
connected to soundpod. Please note:
When on tour is powered,
Power adapter plug not
a green power LED should illuminate.
inserted correctly.
Replace/ Recharge batteries
Batteries are empty
Touch the volume "Up" (+) pad on the vol-
No volume or low volume.
ume control to
un-mute and/or increase the system vol-
ume level.
Note: touching the volume "Down" (-) pad
lowers the system volume. Touching both
(+) and (-) volume control pads at the
same time will mute the system.
Increase the volume level on the audio
Input source is low
source device.
Step 5.
Connect wall adaptor to on
Step 6. P
lug input cable into
tour. Connect adaptor to wall outlet.
on tour. Plug input cable to audio
CAUTION - Remove Adaptor from out-
device. Start audio device.
let before installing or replacing batter-
ies.
Symptom
Possible problem
No Power. Green LED is not on.
Batteries are very low.
Wall Adaptor is not plugged into
soundpod correctly.
Wall adaptor is not receiving AC
power.
Green LED is Flashing and there is
There is no input signal
No Sound.
Input source is low
This product is intended to be supplied by a Listed Direct Plug-in Power Unit marked 'Class 2 and Output rated 6 Vdc minimum 1.0A.
Step 7.
Adjust Volume using "+" to
Step 8.
Green LED indicates that
increase and "-" to decrease. Press
power is on. Flashing Green LED
both to Mute the on tour Press either
indicates no input signal. Amber
button to Unmute.
LED will flash when batteries need
replacement.
www.JBL.com
Solution
Replace batteries with fresh Akaline AAA or fully charged rechargable bat-
teries.
Check connection of wall adaptor.
Place wall adaptor in a known powered outlet. Test outlet with a lamp or
other device.
Connect on tour to known audio source. Test the audio source with head-
phones.
Increase the volume level on the audio source device.
7
