Mark 0664015 R01 Technisches Handbuch Seite 14

5.0 Malfunctions
6.0 Discarding
Whenever the Infra zone control is replaced or removed, it should be recycled or scrapped in
accordance with national regulations and/or local by-laws.
7.0 Attachments
[1] Wiring diagram display
[2] Modbus-list
14
Alert
#####ºC
Reset error: No
The right LED burns
red
------- ºC
Lowest LED doesn't
flash green.
Where Meaning
Display No sensor connected.
Display An Infra has a fault. Through
the display it can be seen in
which zone.
Display An Infra has a fault. Through
the display it can be seen in
which zone.
Internet No sensor connected.
browser
CANbus The display and the controller
aren't connected with each
other.
